Promote the "Belt and Road Initiative", reduce the regulatory pressure on the government, save the operating costs of enterprises and facilitate international trade.
5.0 (1 review) 12 sold certified
One-stop and all-round foreign trade services
| Basics | Height | 310(mm) | |
| Size | 740*500（mm） | ||
| Weight | 72kg | ||
| Exterior material | ABS，Sheet Metal | ||
| Carrier | Shelf | Standard：External dimensions: 660×700×350 Internal dimensions: 600×640×320（mm） or customize the shelf | |
| Rated load | 150kg | ||
| Lifting height | 50mm | ||
| Lifting speed | 5mm/s | ||
| Use Environment | Water-proof & Dust-proof | Whole body IP43, battery IP66 | |
| Operating temperature | -10℃~65℃；UV resistance; Corrosion resistant | ||
| Storage temperature | -20℃~65℃ | ||
| Charging temperature | 5~40℃（indoor） | ||
| Display&touch | No screen，Using compatible terminal control (cloud, PC, mobile, PAD) | ||
| Network Communication | 4G | Support FDD B1/B3/B5/B8,TDD B38/39/30/41 | |
| 5G | Supported, need to add 5G accessories | ||
| Data quota | 2G/ month for each robot | ||
| WIFI | Wifi module（AP6256）2.4G&5GHz，support 802.11a/b/g/n/ac protocal | ||
| Bluetooth | Bluetooth 5.0，BLE | ||
| OS | Linux(Ubuntu) | ||
| Sensors | LiDAR1 | Detection zone：360º，Detection range：0.02～40m | |
| LiDAR2 | Detection zone：140º，Detection range：0.02～12m | ||
| RGB camera | 215°FOV，resolution 1280*720 | ||
| IMU | 6DOF；Rate dynamic range：±2000dps；Precision：0.01° | ||
| Wheel speed indicator | odometer | ||
| Charging & Battery life | Battery | Charging voltage：24V | |
| Capacity：30000mAh | |||
| Battery life ：10h Use charging pile to achieve 7*24h service | |||
| The time it takes to fully charge：5.5h | |||
| Adapter | Working voltage：100~240VAC、50/60Hz | ||
| Charging pile | Dimension：375mm*160mm*355mm | ||
| Weight：4.35kg | |||
| Input：100-240V~50/60 Hz | |||
| Output：29.4V==7.0A | |||
| Control | Chassis CPU | ARM® Quad-core Cortex-A72 1.5Ghz | |
| Chassis GPU | VideoCore VI | ||
| Chassis memory | RAM：4GB binary channels LPDDR4；ROM：32GB High speed eMMC | ||
| Picture processing | Support OpenGL ES 1.1/2.0/3.0,OpenCL1.2,Directx11 | ||
| Embedded high performance 3D acceleration hardware | |||
| H.264/H.265/VP9 up to4Kx2K@60fps H.264/H.265 The decoder supports 10bit decoding | |||
| 1080P multi-format video decoding, support H.264, VP8 and MVC | |||
| Other firmware | indicator light | LED (Programmable, support segmented control) | |
| Emergency stop | 2 | ||
| Loudspeaker | 4Ω10W Supports TTS/ audio stream output | ||
| Movement | Velocity | 1.2m/s Adjustable | |
| Whether support outdoor operation | It can be used in qualified parks/industry zones | ||
| Obstacle climbing | 20mm | ||
| Slope climbing | 8° | ||
| Floor gap width | 35mm | ||
| Passage width | The narrowest width of the robot path needs to be not less than 70cm | ||
| Elevator width | 70cm+ | ||
| Gate width | 70cm+ | ||
| Positioning Accuracy | ±5(mm)/±1(°) | ||
| Software | APP | APP remote management. Use the app program to send robot task, visualize task statistics functions. | |
| Robot management platform | Authorization allocation and business management of robot users; Operational data analysis | ||
| Remote monitoring platform | Real-time status monitoring; Real-time fault alarm and remote processing | ||
| Remote deployment management platform | The robot can be deployed via remote mapping. Operators can scan and edit the map remotely. | ||
| Remote scheduling management platform | Remote cross-space scheduling | ||
| Real-time data visualization | Display real-time status and operational statistical analysis of robots in different businesses. | ||
