Model Name | JD-A300 |
Operating temperature range | -10-55°C |
IP Grade | Ip20 |
AC input Voltage Range | 170-280Vac |
Frequency | 50Hz/60Hz |
Max.AC charging current | 80A |
PV Input | |
Max.power | 5500W |
Max.open voltage | 550V |
MPPT input voltage range | 120-450Vdc |
Max.input current | 100A |
AC Output | |
Rated power | 5500VA/5500W |
Voltage | 230Vac±5% |
Rated Current | 23.9A |
PV Output | |
Max.Power | 5500W |
Max.Charging Current | 100A |
Battery Type | Li-Battery |
Voltage Range | 40-60Vdc |
Rated Voltage | 51.2Vdc |
Battery Energy | 15360WH |
Battery Capacity | 300Ah |
DOD | 93% |
Weight | ≈124KG |
Size | 1360x480x255mm |
