Battery Power

280Ah/314Ah Ternary Lithium Battery

Solar DC Charging

11-60V/ 180W Max

AC Output

Pure Sine Wave Output
AC Continuous Output:300W
AC Max Output:600W
AC Voltage:220VAC±10%
Output Frequency:50HZ/60HZ

DC5521*4 Output

12V/7A

USB1,2 output

QC3.0 output 5V3A; 9V2.5A; 12V2A 24W Max

USB3,4 output

QC3.0 output 5V3A; 9V2.5A; 12V2A 24W Max

TYPE-C1 output

5V-3A 9V-3A 12V-3A 15V-2A 20V-3A 60W-Max

TYPE-C2 output

5V-3A 9V-3A 12V-2.5A 30W-Max

LED light

Maximum power 3W; Full light/
half light/slow flashing/third gear light

Operation
temperature

-10℃~40℃

Work Humidity

20%~85%RH

Storage Temperature

-20℃~60℃

Storage Humidity

20%~85%RH

Life cycle

≥2000 times

Charge While
Discharge

Support

Product Size

275*190*130mm

Product Single
 Weight

9.0KG

Multi-Safety
Protections

Short-circuit protection
Over-current protection
Over-voltage protection
MultiSafety Protections
Low-voltage protection
Over-load Protection
 Over-temperature protection

Certification

GB;ROHS

Accessories

1 x User manual

Item               Outputs

USB Outputs

Type-C1
Outputs

Type-C2
Output/Input

DC/Cigarette
Lighter

USB1,2

USB3,4

TYPE-C1

TYPE-C2

DC/Cigarette
Lighter

Output Voltage Range(V)

5-12V

5-12V

5-20V

5-12V

12V

Ripple & Noise(mV) Vp-p

<200mV

<200mV

<500mV

<500mV

<500mV

Output Current

2.0A

2.0A

2.2-3A

2.2-3A

7A

Over Current point

>3.6A

>3.6A

>3.6A

>3.6A

>7.5A

Rated Power

24W Max

24W Max

60W Max

30W Max

84W Max

Over-Load Protection

Self-recover
when loads are removed

Locked,need re-start

Short-Circuit Protection

Self-recover
when loads are removed

Locked,need re-start

Remark

1.Ripple&Noise test method: Connect the unit and the loads by a 30cm long stranded wire.Load is connected with A 0.1uF ceramic disk
capacitor & 10uF electrolytic (low ESR) capacitor. Test the load with 20M oscilloscope.
2.The left and right USB ports carry only 5V 2.4A 12W each at the same time.

Item                                   Range

Min

Typical

Max

Unit

Output Voltage Range(V)

198

220

242

V

Output Frequency

50HZ/60HZ

HZ

Output Waveform

Pure Sine Wave

Rated Power

Resistive load

300W

W

Inductive load

300W

capacitive load

300W

Output VA

220VA

VA

Surge power (Resistive load)

600W@1s

W

Standby power

<5W

W

Efficiency

>80%

%

Overload Protection Mode

Turn off output, recover after overload removal

short circuit protection Mode

Tum off output, short circuit after removal

Over Temperature protection Mode

Tum off output, short circuit after removal

Over Temperature Protection Valve

≥65(cell surface)

℃

Heat-Dissipating Method

Built-in Cooling Fan
/AL case

Fan to Run When Temperature Meets

≥40(environment temperature of front
radiator)

℃

Remark

AC output and DC output can be used
simultaneously, but the total output power
can not be greater than 300W

Item               Range

Min

Typical

Max

Unit

Remark

Battery Type

Ternary Lithium Battery

Battery Pack

single cell

Battery Capacity

280Ah/314Ah

Wh

Charge Voltage

2.5

3.6

V

product

Charge cut-off Voltage

V

battery

Charge Current

A

battery

Under/Over
Voltage
Protection

By
Hardware
(BMS)

2.7V

V

Battery

Efficiency

≥87%

Time of Charging

PD charging

16H

18H

20H

DC charging

6H

7H

8H

Charged state

Electricity level

LED1 twinkling

0-20%

LED1 lighting、LED2 twinkling

20-40%

LED1、LED2 lighting、LED3 twinkling

40-60%

LED1、LED2、LED3、LED4 twinkling

60-80%

LED1、LED2、LED3、LED4、LED5 lighting

80-100%

Discharge condition

Electricity level

LED1、LED2、LED3、LED4、LED5 lighting

80-100%

LED1、LED2、LED3、LED4 lighting

80-60%

LED1、LED2、LED3 lighting

60-40%

LED1、LED2 lighting

40-20%

LED1 lighting

20-5%

LED1 twinkling

< 5%

Panel button function

Keystrokes

Functional description

turning on/off LED

Click to turn on/toggle LEDs long press to turn off LEDs

turning on/off DC/USB

Click to Click to turn
on/off DC/USB

turning on/off AC inverter output function

Press and hold to turn on/off the AC inverter output function.
